History of Vitamin D:1650 to present - March 2022

Historical aspects of vitamin D.

2022 Mar 1;EC-21-0594. doi: 10.1530/EC-21-0594.
Glenville Jones
Craine Distinguished Professor of Biochemistry. Department of Biomedical and Molecular Sciences Queen’s University, Kingston. Ontario. Canada K7L 3N6 Email: gj1 at queensu.ca

Vitamin D has many physiological functions including upregulation of intestinal calcium and phosphate absorption, mobilization of bone resorption, renal reabsorption of calcium as well as actions on a variety of pleiotropic functions. It is believed that many of the hormonal effects of vitamin D involve a 1,25-dihydroxyvitamin D3-vitamin D receptor (VDR)-mediated transcriptional mechanism involving binding to the cellular chromatin and regulating hundreds of genes in many tissues. This comprehensive historical review provides a unique perspective of the many steps of the discovery of vitamin D and its deficiency disease, rickets, stretching from 1650 until the present. The overview is divided into four distinct historical phases which cover the major developments in the field and in the process highlighting the: a) first recognition of rickets or vitamin D deficiency; b) discovery of the nutritional factor, vitamin D and its chemical structure; c) elucidation of vitamin D metabolites including the hormonal form, 1,25-dihydroxyvitamin D3; d) delineation of the vitamin D cellular machinery, functions and vitamin D-related diseases which focused on understanding the mechanism of action of vitamin D in its many target cells.
 Download the PDF from Vitamin D Life

Introduction

The history of vitamin D is a rich and storied subject and is now over 350 years old. It began in the early 1600s with the first descriptions of the human deficiency disease: rickets in children and osteomalacia in adults. Of course, there were no precise medical details that distinguished it from other bone diseases but treatises describing the symptoms and lithographs from that time showing bone deformities resembling rickets leave little doubt that it was vitamin D deficiency. It took another 250 years to define the cause of vitamin D deficiency in the 19001920 period when physicians and biochemists elucidated the role of sunlight and identified the chemical structure of the two main forms of the vitamin D molecule, vitamin D2 and vitamin D3. Another 50 years elapsed before the metabolism of vitamin D was first described in 1967 and the active form of vitamin D, namely 1,25-dihydroxyvitamin D (1,25-(OH)2D) discovered. The period of time since has witnessed the exciting realization that vitamin D has its own set of dedicated specialized machinery consisting of transport proteins, metabolic enzymes and vitamin D receptor to mediate the actions of vitamin D, not only in bone, but in many other tissues around the body where it has a myriad of different physiological effects.
Before we get into the history of vitamin D, let us first remind the reader of the general aspects of its nomenclature, origins and principal functions. Vitamin D is a steroidal substance required by all vertebrates including humans to maintain blood calcium and phosphate within a narrow normal range and thereby support a healthy skeleton, muscle contraction, immune function and optimal cellular functions in many locations around the body [1]. The name vitamin D is a term coined by nutritionists, and is not a chemical term, which is defined as “a substance with anti-rachitic properties that will cure rickets In human biology, vitamin D usually refers to two substances: vitamin D3 (usually known as cholecalciferol) of animal origin and vitamin D2 (referred to as ergocalciferol) of plant or fungal origin. These two forms have roughly equal potencies, similar metabolic patterns and identical effects in the body.

Because of the four phases of vitamin D history, this review is divided into four sections each summarizing one particular time period:

• 1: 1650-1890: History of vitamin D Deficiency (Rickets)
• 2: 1890-1930: History of the discovery of vitamin D and its structural elucidation
• 3: 1930-1975: History of the discovery of vitamin D metabolites including 1,25-(OH)2D3
• 4: 1975-Present: History of the discovery of the vitamin D cellular machinery, functions and vitamin D-related human diseases.

Since the different facets of the history of vitamin D represent interesting topics, and span
many centuries, they have been reviewed by many previous historians, including the current
author, and interested readers are invited to further access these because they focus on different
aspects of the overall story [2-8].

1650-1890: History of vitamin D Deficiency (Rickets)

There is no doubt that rickets was prevalent in Europe long before it was recognized as a
specific disease in the 15th Century but the earliest documentation of the word “rickets” was in a
domestic receipt book of an English family in 1632 and the earliest printed record of rickets as a
disease causing death in the London Bill of Mortality in 1634 [reviewed by 2-4]. The term rickets
is thought to have its origins in the verb in the Dorset dialect to “rucket”, which means to breathe
with difficulty. However, some claim the term rickets is derived from the Anglo-Saxon word
“wrikken”, meaning to twist. Rickets and osteomalacia were first clearly described by Daniel
Whistler in the Netherlands (1645) as a condition in which the skeleton was poorly mineralized
and deformed [9]. Francis Glisson (1650) provided the first documented records with his book
zentitled “De Rachitide” first published in Latin in 1650 and then translated into English in 1671
[10]. It features a lithograph of children with bowing of the legs and skeletal deformities which
are the hallmarks of vitamin D deficiency. One of those Glisson lithographs was reproduced as a
frontispiece in a landmark treatise on “Rickets including Osteomalacia and Tetany” by AF Hess
in 1929 [11]. It is reproduced here as Figure 1.

A more recent definition of vitamin D deficiency has grown to include defective
chondrocyte differentiation, lack of mineralization of the growth plate but the common feature of
vitamin D deficiency is insufficiently mineralized or calcified bone matrix [1,12,13]. Rickets is
characterized by a deformed and misshaped skeleton, particularly bending and bowing of the long
bones and enlargement of the epiphyses of the joints of the rib cage, arms, legs and neck. Victims
have painful movements of the rib cage and difficulty breathing. In China, medical texts refer to
deformities of the rib cage in severe rickets as “chicken breast” [5]. Severe rickets is often
accompanied by pneumonia. The loss of the important role of vitamin D in strengthening the
immune system compounds this problem. Though rarely is rickets life-threatening, it certainly
lowers the quality of life for the afflicted individual and leads to secondary problems. One of these
secondary effects of rickets occurs in young women who had vitamin D deficiency in childhood
causing deformities of the pelvis which result in difficulties in childbirth [14]. Sorter [14]
speculates that rickets in early life must have resulted in numerous deaths of women during their first delivery.
Vitamin D deficiency is partly the result of inadequate skin synthesis of vitamin D3 from 7-dehydrocholesterol compounded by a low dietary intake of vitamin D2 from plant or fungal sources or vitamin D3 from animal products. The advent of the Industrial Revolution in Western Europe heralded in massive air pollution in the form of smoke from mills and burning of fossil fuels. This dramatically reduced the amount of UV light reaching the ground. Since the workers needed for these new industrial jobs were required to move from their rural locations into dingy, poorly-lit cities, their exposure to UV light diminished and skin synthesis of vitamin D was reduced. Rickets resulted and was associated with lack of exposure to sufficient sunlight. Thus the 18th and 19th centuries saw a higher increase in rickets in the industrialized cities of northern Europe. The Dickensian character Tiny Tim, of the novel A Christmas Carol, clearly represents a child with a deformed skeleton who must have been a common sight in the dark cities of the late 19th century [7]. Rickets was particularly prevalent in the industrialized Britain of the 16th-20th centuries and thus it is no surprise that it was referred to in old texts as “the English disease” [7,15].
Despite the fact that rickets seemed to be associated with lack of exposure to sunlight, by the late 1700s some including Percival [16] in the UK were advocating the use of cod-liver oil for the treatment of rickets suggesting a nutritional aspect to vitamin D. In contrast, in the early 1800s Sniadecki [17] in Poland was documenting the differential incidence in city-dwellers and rural- dwellers suggesting some environmental factor was involved. He speculated that sunlight or fresh- air might be involved in the etiology of the disease. By the end of the 19th century, a rigorous debate roared on whether rickets was caused by the lack of some dietary substance or an environmental factor and how could these two points of view be reconciled.

1890-1930: History of the discovery of vitamin D and its structural elucidation

By the 1890s some researchers such as Owen [18] and Palm [19], who clearly supported the environmental theory, produced evidence that there were big geographical differences in the incidence of rickets in different parts of the UK and northern and southern China. Palm, a medical missionary, went on to suggest that exposure of children to sunlight would cure rickets [19]. Subsequently, researchers in Europe and the USA namely Buchholtz (1904), Raczynski (1913), Huldshinsky (1919) and later Chick (1922) Hess and Weinstock (1924) performed experiments in which laboratory animals and children with rickets could be cured with sunlight or light from mercury arc lamps [7, 20-24]. This clearly demonstrated that lack of exposure to UV light was one cause of rickets.
But the proponents of the theory that a dietary factor could also be involved continued with their experiments too. The early 20th century was a momentous period in nutritional research in which nutritionists showed that a diet of highly purified carbohydrates, protein, fat and salt is unable to fully support growth and life of experimental animals [25]. By adding various “trace factors” researchers were able to restore growth and a full range of physiological actions. The first of these trace factors was thiamin discovered by Funk [26] which cured neuritis in what Funk termed the “vital amine or vitamin theory”. Thiamin was later renamed vitamin B1 but it was one of a number of vitamin substances that are defined as “trace compounds which are derived from the diet and are required in small amounts per day and perform an essential role critical to life”. Vitamin D was identified as one of these substances playing a critical role in skeletal growth and calcium & phosphate homeostasis. However, strictly speaking vitamin D has been misnamed since it can also be derived from exposure to UV light and is not required to be in the diet. In practise and for a variety of social and religious reasons, many populations around the world do not receive adequate UV light, especially during the winter months, so that a dietary intake is essential.

The discovery of the nutritional factor, later termed vitamin D by McCollum [27], came
largely as the result of the work of a number of researchers: Mellanby, McCollum, Steenbock and
Hart working independently. Sir Edward Mellanby [28] in the UK reasoned that rickets might be
due to a dietary deficiency and managed to produce beagle dogs with severe rickets by feeding
them oatmeal and then cured their rickets with cod-liver oil. Since cod-liver oil is a mixture of
lipids and a rich source of vitamin A, it was not clear what the active ingredient might be.
McCollum [29], working firstly at the U Wisconsin and then Johns-Hopkins, heated & bubbled
oxygen through the cod-liver oil to destroy the vitamin A and found that the product still cured
rickets. Building on the new vitamin nomenclature, he termed the new substance vitamin D. But
how was the field to reconcile the apparently unconnected findings that UV light and a nutritional
substance termed vitamin D could both cure rickets? Harry Steenbock also working at the U
Wisconsin-Madison performed the definitive experiment. Steenbock and Black experimented with
the diets of goats and found that sunlight or UV irradiation of the animals or their diets resulted in
rickets being cured in the goats [30]. Steenbock traced the bioactive substance in irradiated food
to the non-saponifiable fraction of lipids in the diet and showed that it cured rickets [31]. Dietary
vitamin D was born.
Subsequently, Steenbock was able to show that irradiated yeast contained significant
amounts of vitamin D, later shown to be vitamin D2; and that the yeast could be irradiated and
added to milk which formed the basis of the first food fortification with vitamin D [5]. Though,
Steenbock and the University of Wisconsin filed a patent for milk fortification with vitamin D, the
proceeds from this discovery were used to establish the Wisconsin Alumni Research Foundation
(WARF) which was one of the prototypical organizations intended to allow universities to plough
the benefits their research into future research. WARF funded the research of a number of scientists
inside and outside of the vitamin D field, included several Nobel laureates, with the proceeds of
Steenbock’s patent. Furthermore, vitamin D fortification of a variety of foodstuffs (including milk,
margarine, bread and even beer) has become a major nutritional tool in the fight to prevent rickets
and osteomalacia around the world [5].
In the late 1920s, Windaus and his colleagues [32] isolated the key anti-rachitic substance
from a mixture of irradiated plant sterols and named it vitamin D1, although they did not identify
its structure. Later vitamin D1 was shown to be a mixture of vitamin D2 and tachysterol. A British
group headed by Askew [33] successfully identified and determined the structure of the anti-
rachitic, plant-derived sterol as vitamin D2 or ergocalciferol. Windaus’s group confirmed the
structure of vitamin D2 [34] and also isolated and identified the animal-derived, anti-rachitic
vitamin D3 or cholecalciferol and its skin precursor, 7-dehydrocholesterol [35]. For his discovery
of the structures of vitamin D3, 7-dehydrocholesterol and several other sterols, Adolf Windaus was
awarded the 1928 Nobel Prize for Chemistry. (Figure 2)

1930-1975: History of the discovery of vitamin D metabolites including 1,25-(OH)?D3

Chemically synthesized vitamin D2 and vitamin D3 have been available since the 1930s and paved the way for the study of their biological functions and metabolism. The physiological roles of vitamin D are primarily its roles in calcium and phosphate homeostasis [1] and include:
Stimulation of intestinal calcium and phosphate absorption
Mobilization of calcium from bone
Renal reabsorption of calcium
All three of these functions serve to raise blood calcium and phosphate and ensure that these ions are available to ensure health and prevent rickets. Elucidating the details of these physiological functions became the main foci during the 1930-1960 time period and research revealed that vitamin D was intimately connected to the roles of other calcium and phosphate-related hormones including parathyroid hormone (PTH) and calcitonin. Details of these connections are beyond the scope of this chapter and are described in reviews [e.g. 1] and in other articles in this Special Issue.

In the 1960s, there was considerable debate over whether the functions of vitamin D were carried out by vitamin D itself or its possible metabolites. Consequently, intense effort was put into studying the metabolism of vitamin D by using chemically-synthesized radioactive versions of vitamin D2 and vitamin D3. The pioneer in this area was Egon Kodicek at the Dunn Nutritional Laboratories, U Cambridge UK. After 10 years of work, Kodicek [36] concluded that vitamin D was active without being metabolized. In retrospect, the radioactive vitamin D his group were using was insufficiently labeled to detect its metabolites. However, Hector DeLuca, again at the U Wisconsin-Madison, and the final graduate student of Harry Steenbock, synthesized radioactive vitamin D3 with much higher specific activity [37] and was able to demonstrate metabolism to more polar metabolites, the principal one being 25-hydroxyvitamin D3 (25-OH-D3) [38] made in the liver and the first identified natural vitamin D metabolite.

25-OH-D3 proved to be more potent biologically than vitamin D3 and was present in the bloodstream at a higher concentration [38]. We now identify 25-OH-D3 as the principal circulating form of vitamin D. But that is not the extent of vitamin D metabolism. Several other groups then entered or re-entered the picture, including Dr Kodicek’s, as well as that of one of Dr DeLuca’s former graduate students Dr Anthony Norman. Amongst the other polar products of vitamin D3 was a metabolite even more potent than 25-OH-D3, namely 1a,25-dihydroxyvitamin D3 (1,25- (OH)2D3) which is now universally accepted as the hormonal form of vitamin D3. Several groups including Dr Kodicek’s [39] Dr Norman’s [40] and Dr DeLuca’s [41] were credited with playing a role in the discovery and/or in the structural identification of 1,25-(OH)2D3. Kodicek’s group administered a mixture of radioactive [4-14C] & [1-3H]vitamin D3 preparations and showed that one polar metabolite lost its tritium atom during metabolism that aided in its identification as a 1- hydroxylated compound [39]. Furthermore, the Cambridge group also showed that the hormone was biologically generated in the kidney [39,42]. Dr Norman’s group showed that the new metabolite was associated with the chromatin of intestinal mucosal cells and had greater biological activity than even 25-OH-D3 [40]. Holick et al [41] showed that the additional 1-hydroxyl group was in the 1a- orientation and supported their identification of the metabolite as 1a,25-(OH)2D3 with mass spectrometry. Chemically synthesized 1,25-(OH)2D3 was first produced by Semmler et al [43] and made commercially by a group headed by Dr Milan Uskokovic at Hoffmann-La Roche in the early 1970s and is known clinically by the name calcitriol [44].
The identification of the principal metabolites: 25-OH-D3 and 1,25-(OH)2D3 spawned a frenzy of research activity in the vitamin D area and the discovery of a number of other vitamin D metabolites [1]. Amongst these are the principal metabolites of vitamin D2 including 25-OH-D2 [45], 1,25-(OH)2D2 [46] and 24,25-(OH)2D2 [47]. Also identified in that mixture of metabolites arising from radioactive vitamin D3 were several compounds that are presumed to be inactive catabolites including: 24,25-(OH)2D3, 25,26-(OH)2D3, 25-OH-D3-26,23-lactone, 1,24,25-(OH)3D3 and calcitroic acid. [48-53] A summary of the main metabolites of both vitamin D3 and vitamin D2 along with their tissue source, biosynthetic enzyme, details of first reporting and biological role is presented in Table 1 and depicted in a metabolic pathway diagram (Figure 3).

1975-Present: History of the discovery of the vitamin D cellular machinery, functions and vitamin D-related human diseases.

The discovery of the active forms of vitamin D heralded in a search for:the signal transduction mechanisms to explain how 1,25-(OH)2D3 was able to produce its various biological effects;identification of the enzymes responsible for the synthesis and catabolism of 1,25-(OH)2D3;
a clear understanding of the regulation of the vitamin D endocrine system
These studies began almost as soon as metabolism was recognized in the late 1960s when Mark Haussler, in AW Norman’s laboratory, demonstrated that vitamin D metabolites associated with the chromatin [54]. Clear evidence of the protein that is now termed, the vitamin D receptor (VDR) was produced by Haussler’s lab [55]. The VDR protein from various species was later purified and its gene cloned by Haussler’s group [56,57]. Study of the pure protein has led to a determination of its crystal structure [58]. Parallel to these investigations of the VDR have come other studies on how it works both at the whole-body level in calcium and phosphate homeostasis and other pleiotropic functions [1,8,59] and at the cellular level in a classic steroid hormone superfamily like process through a transcriptional mechanism [60]. Over the past 30 years, Mark Haussler, Wes Pike & colleagues [61] have demonstrated that 1,25-(OH)2D3 works through a VDR-mediated mechanism that involves many coactivators and repressors to directly interact with and regulate hundreds of genes around the body. Other researchers, most notably Anthony Norman , have proposed that some of the actions of vitamin D occur through rapid non-genomic signaling pathways, possibly involving a plasma membrane vitamin D receptor but this protein has never been fully characterised at the molecular level. Nevertheless, there remains some uncertainty that all vitamin D ligands and analogs produce their effects through a genomic VDR mechanism
.
The history of two other components of the vitamin D machinery deserve some mention. These are vitamin D-binding globulin [64,65] and the cytochromes P450-containing enzymes that metabolize vitamin D into its many metabolites [66]. Being a fat-soluble vitamin, Vitamin D requires a protein to transport it around the body and the vitamin D-binding globulin (usually abbreviated as DBP) performs this function. DBP was first identified as Gc (group specific component) in the 1970s and its properties have been reviewed extensively by the father figure of the field Roger Bouillon, U Leuven, Belgium [65]. DBP has a high affinity for most of the main metabolites of vitamin D, most notably 25-OH-D, and because of this 25-OH-D is the main circulating form in the blood.
The cytochrome P450-containing enzymes (CYPs) responsible for vitamin D metabolism were first studied in the early 1970 in tissue extracts of liver and kidney [67,68,69]; then in tissue culture and given names based upon their hydroxylation activity: 25-hydroxylase, 1a-hydroxylase and 24-hydroxylase. In the early 1990-2005 period all three enzymes were purified, cloned and expressed in cell culture systems, principally by Canadian group of St-Arnaud [70] as well as the Japanese groups of Kato S [71], Okuda [72] and Sakaki [73,74] as well as Russell’s group at the U Texas [75]. The 3 enzymes are now known as CYP2R1, CYP27B1 and CYP24A1. A review of the CYP field and how these enzymes operate & how they are regulated is provided [66]. A summary of the history of the signal transduction protein machinery for vitamin D including VDR, DBP and the various CYPs is provided in Table 2.
No review of the recent history of vitamin D would be complete without an overview of how defects in vitamin D metabolism result in human disease. It is now evident that vitamin D deficiency and rickets are caused by several genetic and acquired errors in vitamin D metabolism which involve any of the major protein components of the vitamin D machinery described above. These are compiled into Table 3 where we document the disease name, the component of the vitamin D machinery affected, as well as the publication first describing it. Besides diseases involving too little 1,25-(OH)2D3 and resulting in rickets, diseases involving too much 1,25- (OH)2D3 which cause hypercalcemia are also included in Table 3. Most of these diseases involving a shortage of 1,25-(OH)2D3 are now treated with vitamin D analogs which were developed from knowledge of the metabolism and biological actions of vitamin D. Currently approved and marketed vitamin D analogs are listed in Table 4 along with their original publications.

Conclusions

The history of vitamin D is indeed a rich subject which has already stretched over 350 years and involved the 4 phases described in this review. While the chemical entity, vitamin D remained unknown for all but 100 of those years, the significant medical consequences of vitamin D deficiency were evident for the whole of that time. Many physicians, nutritionists, biochemists, chemists and molecular biologists have worked to elucidate our current knowledge of the nature of vitamin D in addition to its metabolism, mechanism of action and biological activities. That knowledge has paid dividends by providing new therapies for the treatment of deficiency and excess vitamin D action. The field of vitamin D research is arguably one of the highlights of modern medicine.

Acknowledgements
This review is dedicated to Emeritus Professor Hector F. DeLuca, Department of Biochemistry, University of Wisconsin-Madison, who pioneered the renaissance period in the vitamin D field in 1967 with the discovery of the first vitamin D metabolite, 25-OH-D3. Dr DeLuca spawned a revolution which led to a clear understanding of how vitamin D works in calcium and phosphate homeostasis and led to a series of vitamin D analogs that can be used to treat diseases involving dysfunctional vitamin D metabolism. The author joined the DeLuca laboratory in 1972, and as a result he had the opportunity to meet, collaborate with, and celebrate many of the main players cited in this historical review. The author thanks them all for their important contributions.
